AVJ5

Ash/Maple/Rosewood

  • Enhanced version of traditional J tone of a bass
  • European Ash body with nitrocellulose lacquer
  • Madagascar Rosewood fingerboard with Pearl blocks
  • Hipshot stainless steel tuners & bridge
  • Nordstrand ® BigSplitman & Big Single pickup
  • Nordstrand ® 3B5A electronics
  • Neck plate with custom engraving
  • Certificate of origin with used woods CITES
Price from 2 595,00 € + VAT

Gallery

Technical Specifications

Show

Woods

  • Body: 2 pieces, European Ash
  • Neck: 1 piece, Hard Maple
  • Width at the nut: 47.5 mm
  • Width at the 20.fret: 74 mm
  • Fingerboard radius: 12"/305 mm
  • Fingerboard: Madagascar Rosewood
  • Positional marks on the fingerboard: Pearl blocks
  • Positional marks at the side of the fingerboard: Pearl
  • Nut: White Tusq
  • Body finish: Seafoam Green High Glossy
  • Neck finish: Natural, Satin Matt

Hardware

  • Bridge: Hipshot Vintage Style, chrome
  • String spacing at the bridge: 18 mm
  • Tuning machines: Hipshot Ultralite, chrome
  • Frets: 20x Medium Jumbo 2.4 mm wide
  • Control knobs: Metal knobs with flat head, chrome
  • Strap pins: Dunlop Strap locks, chrome
  • Strings: Elixir Nickel Roundwound 0.045-0.125
  • Weight: 5.2 kg

Electronics

  • Neck pickup: Nordstrand Big Single
  • Bridge pickup: Nordstrand Bigman
  • Electronics: Active/Passive electronics Nordstrand 3B5-b
  • Wiring: 2x volume for each pickup, 1x stacked Tone Control/Mids, 1x mini switch to passive, 1x mini switch for coil tapping of bridge pickup series/single/parallel, 1x stacked knob Treble/Bass
  • Capacitor: Orange Spraque 47nF
  • Battery: 1x 9V
  • Pickguard: 3ply Tortoise pickguard
  • Output jack: Stereo 6.3 mm
