Technical specifications



  • Body: Spalted Maple top, Mahogany resonate plate and Black Walnut
  • Neck: 5 pieces laminate, Hard Maple/Wenge
  • Width at the nut: 46 mm
  • Width at th 24.frets: 80 mm
  • Fingerboard radius: 16"/407 mm
  • Fingerboard: Birdseye Maple
  • Binding: Rosewood with Maple and Ebony stripes
  • Positional marks on the fingerboard: Ebony
  • Positional marks at the side of the fingerboard: Pearl
  • Nut: Ebony
  • Body finish: Natural, Satin Matt
  • Neck finish: Natural, Satin Matt


  • Bridge: Gotoh 404SJ-5, Gold
  • String spacing at the bridge: 18 mm
  • Tuning machines: Gotoh GB707, Gold
  • Frets: 24x, Jumbo 2.9 mm wide
  • Control knobs: Metal knobs with oval head, Gold
  • Strap pins: Schaller strap locks, Gold
  • Strings: Elixir Nickel Roundwound 0.045-0.130
  • Weight: 4.60 kg


  • Neck pickup: Bartolini XXM45-N
  • Bridge pickup: Bartolini XXM45-B
  • Electronics: Active/Passive electronics Aguilar OBP-3
  • Wiring: 1x volume with push/pull to passive, 1x blend, 1x bass, 1x mid with push/pull for switching between 400/800 Hz frequency, 1x treble, 2x serie/single/parallel switch for each pickup
  • Battery: 1x 9V
  • Output jack: Stereo 6.3 mm
