AVS

Box Elder/Maple/Swamp Ash

  • Cícero Lee's signature model
  • Crazy cool looking Box Elder decorative top
  • Laminate 3 piece hard Maple neck
  • Hipshot black hardware
  • African Ebony fretboard with 26 frets
  • Nordstrand ® Dualcoil pickups with Ebony thumb rest bar
  • Stacked vol/tone controls for each pickup
  • Satin Matt lacquer
  • Certificate of origin with used woods

Gallery

Technical specifications

Show

Woods

  • Body: Box Elder top, Swamp Ash back
  • Neck: 3 piece laminate, Hard Maple
  • Width at the nut: 56 mm
  • Width at th 24.frets: 92 mm
  • Fingerboard radius: 16"/407 mm
  • Fingerboard: African Ebony
  • Positional marks on the fingerboard: none
  • Positional marks at the side of the fingerboard: Pearl
  • Nut: Ebony
  • Body finish: Natural, Satin Matt
  • Neck finish: Natural, Satin Matt

Hardware

  • Bridge: Hipshot A style, Aluminum, black
  • String spacing at the bridge: 18 mm
  • Tuning machines: Hipshot Ultralite, black
  • Frets: 26x, Jumbo 2.9 mm wide
  • Control knobs: Metal knobs with oval head, black
  • Strap pins: Schaller strap locks, black
  • Strings: Elixir Nickel Roundwound 0.045-0.130
  • Weight: 4.1 kg

Electronics

  • Neck pickup: Nordstrand Big Single
  • Bridge pickup: Nordstrand Big Single
  • Electronics: Passive electronics
  • Wiring: Stacked volume/tone control for each pickup
  • Output jack: Mono 6.3 mm
