Technical specifications



  • Body: Figured Ash top, Mahogany resonant plate and Flamed Maple
  • Neck: 5 pieces laminate, Maple/Wenge
  • Width at the nut: 46 mm
  • Width at the 24.fret: 78 mm
  • Fingerboard radius: 16"/407 mm
  • Fingerboard: African Ebony
  • Positional marks on the fingerboard: N/A
  • Positional marks at the side of the fingerboard: Pearl
  • Nut: Ebony
  • Body finish: Natural, Satin Matt
  • Neck finish: Natural, Satin Matt


  • Bridge: Gotoh J510B-5 brass, black
  • String spacing at the bridge: 19 mm
  • Tuning machines: Gotoh Gb-707, black
  • Frets: 24x Jumbo 2.9 mm wide
  • control knobs: Metal knobs with oval head, black
  • Strap pins: Schaller Strap Locks, black
  • Strings: Elixir Nickel Roundwound 0.045-0.130
  • Weight: 5 kg


  • Neck pickup: Aguilar Super Single
  • Bridge pickup: Aguilar Super Single
  • Electronics: Active/Passive electronics Aguilar OBP-3, 3 band
  • Wiring: 1x volume with push/pull to passive, 1x blend, 1x bass, 1x mid with push/pull for switching between 400/800Hz, 1x treble
  • Battery: 1x 9V
  • Ouput jack: Stereo 6.3 mm
