Technical Specifications

Show

Woods

  • Body: Claro Walnut top, Alder core and Flamed Maple back
  • Neck: 7 piece laminate, Hard Maple & Wenge
  • Width at the nut: 56 mm
  • Width at th 24.frets: 95 mm
  • Fingerboard radius: 16"/407 mm
  • Fingerboard: African Ebony
  • Positional marks on the fingerboard: Maple veneer
  • Positional marks at the side of the fingerboard: Pearl
  • Nut: Ebony
  • Body finish: Natural, Satin Matt
  • Neck finish: Natural, Satin Matt

Hardware

  • Bridge: Hipshot A style Piezo, Aluminum, black
  • String spacing at the bridge: 18 mm
  • Tuning machines: Hipshot Ultralite, black
  • Frets: Maple veneer
  • Control knobs: Metal knobs with oval head, black
  • Strap pins: Schaller strap locks, black
  • Strings: Elixir Nickel Roundwound 0.032-0.130
  • Weight: 4.3 kg

Electronics

  • Neck pickup: Bartolini XXM56 Dualcoil
  • Electronics: Active/Passive electronics AV Basses 3band
  • Wiring: Magnetic pickup volume, Piezo pickup volume, 1xEQ bass, 1x EQ mids, 1xEQ treble
  • Output jack: stereo 6.3 mm
