Woods

  • Body: AAA quilted maple top, purpleheart layer and African mahogany
  • Body: Resonant block Zebrano/Macassar Ebony
  • Neck: 11 piece laminate, Maple/Purpleheart/Wenge
  • Width at the nut: 58 mm
  • Width at th 26.frets: 93 mm
  • Fingerboard radius: 16"/407 mm
  • Fingerboard: African Ebony
  • Fingerboard binding: Rosewood with contrasting line maple/ebony
  • Positional marks on the fingerboard: none
  • Positional marks at the side of the fingerboard: Pearl
  • Nut: Tusq
  • Body finish: Natural, Satin Matt
  • Neck finish: Natural, Satin Matt

Hardware

  • Bridge: Hipshot A style, Aluminum, black
  • String spacing at the bridge: 18.5 mm
  • Tuning machines: Hipshot Ultralite, black
  • Frets: 26x, Jumbo 2.4 mm wide
  • Control knobs: Metal knobs with oval head, black
  • Strap pins: Dunlop strap locks, black
  • Strings: Elixir Nickel Roundwound 0.032-0.130
  • Weight: 4.8 kg

Electronics

  • Neck pickup: Aguilar SuperDouble Dualcoil 6
  • Bridge pickup: Aguilar SuperDouble Dualcoil 6
  • Electronics: Active/passive electronics AV basses 3 band EQ with parametric mids
  • Wiring: Main volume with push/pull to passive voicings, blend between pickups, EQ mid control with frequency selector, EQ stacked bass/treble
  • Output jack: stereo 6.3 mm
